Mazda RX-7 VIN Number info

1979 - 1980

USA :
SA2	2	C	500001
SA2				model code RX-7 1979-80
	2			Engine Code (2=12A)
		C		Body Code (C=coupe)
			500001	serial number

World :
SA2	2	C	00	500001
SA2					model code RX-7 1979-80
	2				Engine Code (2=12A)
		C			Body Code (C=coupe)
			00		Factory Code (00=Hiroshima)
				500001	serial number

1981 - 2002

USA :
WMI												World Manufacturer Identifier
			VDS									Vehicle Description Section
									VIS			Vehicle Identification Section
J	M	1	F	B	3	3	1	4	B	0	600001
J												Origin (J=Japan)
	M											Manufacturer (M=Mazda)
		1										Type (1=Passenger Car, 2=truck)
			F									Car Line (F=RX-7)
				B								Generation (B='81-'85, C='86-'91, D='92-'96)
					3							Country Code (3=USA)
						3						Body Style Code (3=coupe, 5=cabriolet)
							1					Misc. ID Code, see table
								4				Check digit
									B			Model Year Code (see list)
										0		Factory Code (0=Hiroshima)
											600001	Serial Number

Misc. ID Code
code	SA/FB	FC '86-'89	FC '90-'91	FC Convertible '90-'91	FD
1	12A Engine	13B EGI Engine	13B EGI, auto shoulder belts	13B EGI, no airbag	13B-REW US spec
2	13B Engine	13B Turbo Engine	13B Turbo, auto shoulder belts	13B EGI, airbag	13B-REW Canadian spec
3			13B EGI, manual seat belts		manual seat belts, dual airbags
4			13B Turbo, manual seat belts

USA Model Year Code
code	year (19..)
B	81
C	82
D	83
E	84
F	85
G	86
H	87
J	88
K	89
L	90
M	91
N	92
P	93
Q	94
R	95
S	96

World :
JMZ	F	B	1	3	1	2	00	600001
JMZ									Manufacturer Mazda Passenger Car
	F								Car Line (F=RX-7)
		B							Generation (B='81-'85, C='86-'91, D='92-2002)
			1						Country code (see list)
				3					Body Style Code (3=coupe, 5=cabriolet)
					1				Engine (1=12A, 2=13B, 3=13B Turbo, B=13B-REW)
						2			Transmission Code (2=Manual 5-speed)
							00		Factory Code (00=Hiroshima)
								600001	Serial Number

Country Code
code	country	steering	dials	engine specs
0	Japan	RHD	km	detox
1	Europe	LHD	km	-
2	Canada	LHD	km	detox, CSA
3	USA	LHD	mi	detox,(Calif),(CSA)
?	Australia	RHD	km	hot
?	UK	RHD	mi	-
( ) = optional CSA = Cold Start Assist (Glycol Injection)

Japan Domestic, all years

SA	2	2	C	500001
SA					model code RX-7 (SA='79-'85 FC='85-'91 FD='91-'02)
	2				Engine Code (2=12A, 3=13B)
		2			xxxxxxxxxxxxxxxxxxxxxxx
			C		Body Code (C=coupe)
				500001	serial number

Serials by Year

Model Year	Production Date	Serial Number	Notes
SA/FB
1979	3/78-6/79	SA22C-500001~SA22C-566640	There are no duplicate serial numbers, e.g. if there is a SA22C-501234, then there is no FB31-501234. It appears that in 1980 and 1981 low-spec export models (base, L, DX, ...) and all Japanese domestic models got SA22C serials whilst high-spec export models (GLS, SDX, ...) got FB31 serials. Highest numbers as listed in Mazda manuals; actually observed: SA22C-6556 and FB1312-6676 (both Euro specs)
1980	6/79-9/80	SA22C-566641~SA22C-629953
1981	7/80-5/81	FB31-500001~FB31-533894
1982	5/81-6/82	FB31-600001~FB31-652106
1983	7/82-10/83	FB31-700132~FB31-770000
1984	9/83-7/84	FB3-800001~FB3-839137	In 1984 two more engine options became available: 12A Turbo for Japan and 13B EGI for USA
1985	7/84-8/85	FB3-850001~FB3-912608
FC
1986	8/85-4/86	100001~140427	New paint colors introduced at 86/04/02
1986	4/86-12/88	140428~500000
1986	6/86-12/86	500001~538438	Turbo II, GXL; New paint colors introduced at 86/12/25
1987	1/87-7/87	538439~600000	Turbo II, GXL
1987	7/87-12/88	600001~700000	Turbo II, GXL; New paint colors introduced at 87/07/01
1987	7/87-12/88	FC35**100001~200000	Convertible
1988	2/88-12/88	500001~600000	Turbo II, GXL, 10th Anniversary Edt
1989	1/89-12/89	700001~800000
1990	1/90-7/90	800001~900000
1991	8/90-7/91	900001~950000
1992	7/91-9/92	FC35**100001~200000	Convertible Mazda manual info suggests Convertible serial nrs are continuous (despite 1990 facelift), although all facelifted export Convertible versions (K/L/M year codes) I have seen have serial numbers in 70**-90** range. After Mazda announced there would be no FD Convertible made, so many orders for FC Convertibles were placed that production continued well into 1992. In all 22,418 Convertibles were built (22,268 up to 8/92 followed by 150 'Final Edition' versions for Japan only).
FD
1993	12/91-8/93	200001~300000
1994	8/93-7/94	300001~310000
1995	7/94-1/96	400001~500000
...			After 1/96 no more export versions were produced
2000	-10/00	~515704	end of E-FD3S
2000	10/00-12/00	600001~600798	GF-FD3S
2002	-8/02	~607290	GF-FD3S
All data based on Mazda parts catalogs and maintenance manuals

Complete production numbers broken down by year can be found on the RX-7 Model Code page.
